Mediclinics Saniflow E05ACS Hand Dryer Auto Sensor

Item Code: E05ACS

Key Features-

* Warm air hand dryer.
* Push-button operated.
* Maximum power and airflow.
* Maximum robustness and vandal-proof.
* Suitable for very high traffic facilities.
* It normally goes along with a soap dispenser.

Components and Materials

* Steel one-piece cover white epoxy coated, 1,5 mm thick.
*Cover fixed to the base by means of 2 vandal-proof lock screws and lock with special Saniflow  wrench.
* Base in aluminium, 3 mm thick, with 4 8 mm holes for wall mounting.
* Fire resistant plastic UL 94-VO fan scroll.
* Universal brush motor, 5500 rpm, F class, incorporates a safety thermostat and a self-resetable thermal cut-off at 120 degC.
* Aluminium centrifugal double symmetrical inlet fan wheel.
* Waved wire NiCr heating element on a mica frame that incorporates a self-resetable safety thermal cut-off at 80 degC.
* Nozzle in chrome plated zamak, 22 inch 1/4 thick.
* Push-button in chrome plated zamak, 22 inch 1/4 thick, that activates an electronic timer with a 35 second cycle.

Technical Specifications

* Voltage - 220-240 V
* Frequency - 50/ 60 Hz
* Electrical isolation - clase I
* Dimensions - 245mm H x 276mm H x 210mm D
* Weight - 4,9 Kg
* Effective airflow - 330 m3/h/ 5500l/min
* Nominal airflow - 470 m3/h / 7800l/min
* Air velocity - 96 Km/h
* Total power - 2250 W
* Motor power - 250 W
* Heating element power - 2000 W
* Consumption - 10 ARPM - 5500
* Air temperature(10 cm distance / 21 degC) - 53degC
* Noise level (at 2 m) - 70 dB (Tested in a sound proof room does not include environmental factors)
* Protection level - IP23
